Model No: 2 ton、3 ton、5 ton

Top Supplier hot sale China Manufacturer Outdoor Warehouse carry tools 2T/3T/5T Customize Counterbalanced Forklift

Fuel Type: Electric

Side Shift: Yes

Capacity : 2000KG / 3000KG / 5000KG

Lift Height:6000MM

Custom:Yes

Additional Info : Outdoor - Warehouse - 4x4 Model - Indoor

Truck Warranty : 1000 HRS or 1 Years truck warranty : Subject to status.
Quantity :
add to cart
Contact Now

Specification Parameter

In today's dynamic outdoor warehouse environment, finding the right handling tools is crucial for efficiency and safety. Among the top suppliers, the hot sale of custom counterbalanced forklifts from China stands out, offering capacities of 2T, 3T, and 5T to meet diverse needs. These forklifts come in various models including diesel forklifts, articulated rough terrain forklifts, conventional diesel forklifts, integrated off-road forklifts, and electric forklift trucks. Notably, the electric forklift models CPD20, CPD30, and CPD50 feature advanced power forms such as lead-acid batteries and lithium batteries, showcasing a commitment to sustainability alongside performance.

The difference between lead acid and lithium batteries for forklifts.

  • Lead-acid batteries offer an affordable upfront cost suitable for businesses with low-frequency forklift use or single-shift operations. However, they demand regular maintenance, including watering and cleaning, which can add to operational costs. With a lifespan typically around 1,500 cycles, they fall short of lithium-ion batteries in terms of longevity. Recharging is time-intensive, necessitating a designated space and a cooldown period post-charging. As the battery discharges, its power output diminishes, potentially requiring swaps during extended use. Additionally, they contain hazardous materials and produce acid fumes, posing environmental and safety concerns if not handled correctly.
  • Despite their higher initial cost, lithium-ion batteries offer long-term savings with significantly lower operational and maintenance expenses. They are maintenance-free, eliminating the need for watering, equalizing, or extensive cleaning thanks to their sealed design. These batteries provide consistent power output throughout their discharge cycle, enhancing forklift performance and operational efficiency. With a lifespan of 5-7 years or 2,000 to 3,000 cycles, lithium-ion batteries outlast lead-acid counterparts by 2 to 3 times, making them a cost-effective and reliable choice for sustained use.

Why electric forklifts are better suited to indoor use?

  • Zero Emissions and Environmental Friendliness
  • Reduced Noise Levels
  • Lower Operating Costs
  • Improved Performance and Efficiency
  • Enhanced Safety Features
  • Economic Considerations


Dimensions and parameters of electric forklift

Model

CPD20

CPD30

CPD50

Power form

Lead-acid battery

Lead-acid battery

Lead-acid battery

/lithium battery

/lithium battery

/lithium battery

Rated load

Kg

2000

3000

5000

Load center distance

mm

500

500

600

Lifting height

mm

3000

3000

3000

Free lifting height

mm

30

30

30

Fork size

L×W×T

mm

1070×120×35

1220×122×45

1220×150×55

Fork distance (outside)

Min./Max.

mm

240/1000

244/1000

300/1360

Mast inclination angle

F/R

mm

6/8

6/8

6/8

Front overhang

mm

400

420

480

Dimensions

Total length

mm

2400

2500

3060

 (excluding forks)

total width

mm

1200

1200

1360

Unraised mast

mm

2080

2080

2300

Raised mast

mm

3550

3550

4120

Safety rack height

mm

2100

2100

2280

Min turn radius

mm

1930

2530

2800

Min right angle channel width

mm

1850

1850

1850

Speed

Driving speed
(full load)

km/h

13.5

13.5

13.5

Lifting speed
(full load)

mm/sec

250

250

250

Speed maxi gradient
 (full load)

%

15

15

15

Weight include battery

Kg

3050

3500

6000

Tire

Front wheel (solid)

6.50-10

28x9-15

250-15

Rear wheel (solid)

5.00-8

650-10

23x10-12

Wheelbase

Front wheel

mm

1140

1140

1140

Rear wheel (solid)

mm

920

920

1080

Wheelbase

mm

1640

1860

2045

Min ground clearance

mm

100

100

180

Motor

Travel motor

kw(60min)

4

8.5

18

Oil pump motor

kw(15min)

3

8.5

21

Controller

AC

AC

AC



Main Features

.The full AC system has precise control, stable operation, and can climb with full load.
.High-performance hydraulic system, low noise, small vibration, and high efficiency.
.The roof guard and the body are welded into an integral structure, with high overall strength.
.Split cast iron counterweight, beautiful and practical, strong and reliable.
.New development of international advanced concepts, reasonable layout, high safety factor of the whole vehicle
.The ergonomically designed control handle is convenient for right-hand lifting and lowering, improving driving comfort.
.Load-sensing full hydraulic system, lightweight, low-noise, and more labor-saving.
.Wide view mast design, clear view

FAQ

Q: What products are included in the custom counterbalanced forklift line?
A: The product line includes 2T, 3T, and 5T custom counterbalanced forklifts designed for outdoor warehouse carry tools.
Q: What type of fuel do these forklifts use?
A: These forklifts are electric-powered and include models with lead-acid batteries and lithium
Q: What are the capacity options available for these forklifts?
A: The forklifts come in capacities of 2000KG, 3000KG, and 5000KG.
Q: How high can these forklifts lift?
A: The lift height can reach up to 6000MM.
Q: Are these forklifts customizable?
A: Yes, customization options are available upon request.
Q:VITIAL forklifts are all customisable.
A: Steering wheel, wheels, reversing system, seats, LED lights, handling props, multifunction LCD display.Cab.A/C.3 mast.Lifting height.Side-shifter .
Q: What warranty is offered with these forklifts?
A: They come with a 1000 HRS or 1-year full vehicle warranty, subject to status.
Q: What are the key specifications of the electric forklift models CPD20, CPD30, and CPD50?
A: These models feature power forms of lead-acid and lithium batteries, rated loads of 2000 kg to 5000 kg, load center distances of 500 mm to 600 mm, and lifting heights of 3000 mm.
Q: Can the forklifts be equipped with additional configurations?
A: Yes, optional configurations include lifting height, side-shifter, 3 mast, AC, cab, and various attachments to meet specific operational needs.
